Product Overview
The Shoulder Surgery Support System is a professional Class I medical device specially engineered for standardized patient positioning during open and arthroscopic shoulder surgeries. As a core orthopedic surgical positioning accessory, this adjustable shoulder support system delivers stable, safe, and ergonomic patient fixation, allowing surgeons to obtain maximum and clear surgical access to the shoulder joint. It effectively improves intraoperative operation efficiency while greatly enhancing patient comfort and surgical safety during long-duration upper extremity orthopedic procedures.
Manufactured by Red Sun Medizone, this medical-grade shoulder positioning system adopts high-precision industrial processing and premium medical materials. With ultra-wide compatibility with mainstream operating tables and multi-dimensional adjustable functions, it has become reliable positioning equipment for orthopedic surgery centers and hospitals worldwide.
Key Features & Technical Specifications
Designed for clinical versatility, structural stability and flexible adjustment, the shoulder surgery support system integrates multiple humanized and high-performance designs to meet complex surgical positioning needs:
Dual Independent Shoulder Board Design: Features separated left and right shoulder boards, supporting flexible independent positioning adjustment to adapt to different surgical sides and personalized operative postures.
Premium Aviation & Medical-Grade Materials: The main frame adopts corrosion-resistant 304 stainless steel, paired with high-precision CNC-machined 6061 aluminum-magnesium alloy components, ensuring lightweight structure, high rigidity, durability and easy high-temperature sterilization.
High-Precision Gas Spring Back Support: Equipped with imported gas spring for stable backrest angle adjustment, with an adjustable range from -15° to +80°, freely switching between beach chair position, lateral position and other common surgical postures.
Full-Range Multi-Directional Head Support: The surgical headrest supports comprehensive displacement adjustment: 330mm vertical up/down travel, 110mm forward/backward travel, and 90mm left/right lateral travel, achieving all-round precise head and neck positioning.
Universal Adjustable Side Rail Connector: The side rail mounting range is adjustable from 335mm to 655mm. Adopting plug-in quick-connect structure, it is universally compatible with most mainstream operating table brands and models on the market.
Ergonomic Large-Area Back Support: Standard back support size measures 560mm × 585mm, matched with 60mm thick medical-grade soft mattress, effectively relieving patient pressure and preventing intraoperative discomfort.
Safe and Standard Load Capacity: With a safe working load of 20kg, it provides stable and reliable bearing capacity to fully meet clinical surgical positioning standards.
Convenient Mobile Storage & Transport: Equipped with a dedicated mobile carrier cart, supporting flexible equipment handling, centralized storage and rapid operating room deployment, saving clinical space and preparation time.
Secure Replaceable Fixation Strap: Comes with durable replaceable body strap, realizing firm and safe patient fixation. The detachable design facilitates regular replacement and medical disinfection to meet sterile surgical requirements.
Clinical Applications
This multifunctional shoulder surgery support system is widely applicable to various upper extremity orthopedic surgeries that require beach chair positioning or lateral patient positioning, covering mainstream shoulder surgical scenarios:
Arthroscopic minimally invasive shoulder surgery
Rotator cuff repair and reconstruction surgery
Shoulder arthroplasty and joint replacement procedures
Shoulder fracture fixation and orthopedic repair surgery
Other complex upper extremity orthopedic and shoulder reconstructive surgeries
Manufacturer Strength
Red Sun Medizone focuses on the R&D and production of high-standard surgical positioning systems and orthopedic medical devices. We provide stable, precise and cost-effective surgical auxiliary solutions for global orthopedic and neurosurgical centers, adhering to strict medical quality control systems to ensure reliable clinical performance of every device.
